Designed for contamination-sensitive applications, our oil-free piston compressors deliver clean dry air with robust performance for food, pharma, and electronics plants in Tamil Nadu.
Frank oil-free piston compressors are engineered to deliver guaranteed oil-free air for industries where purity cannot be compromised. The machines use a precision piston sealing system and water-cooled cylinders to keep contamination levels below 1 ppm. This makes them perfect for food packaging, medical device assembly, and electronics manufacturing across South Tamil Nadu.
Our clean air piston series is built with non-lubricated cylinders and food-grade finishes to ensure safe operation in hygiene-sensitive manufacturing facilities.
These units are designed to run dry while delivering stable pressure control, reducing maintenance time and eliminating oil disposal concerns at the plant.
| Model | Pressure | Displacement | Motor (HP) | Air Output |
|---|---|---|---|---|
| OF-P-5 | 8 kg/cm² | 12 CFM / 340 LPM | 5 HP | 10.5 CFM |
| OF-P-7.5 | 8-10 kg/cm² | 18 CFM / 510 LPM | 7.5 HP | 16.5 CFM |
| OF-P-10 | 8-10 kg/cm² | 24 CFM / 680 LPM | 10 HP | 22 CFM |
| OF-P-15 | 8-10-12 kg/cm² | 35 CFM / 992 LPM | 15 HP | 31 CFM |
| Model Selection | Operating Pressure | Power (HP/kW) | Free Air Delivery |
|---|---|---|---|
| OF-P-M-10 | 8 kg/cm² | 10 / 7.5 kW | 20–18 CFM |
| OF-P-M-15 | 10 kg/cm² | 15 / 11 kW | 30–26 CFM |
| OF-P-M-20 | 10 kg/cm² | 20 / 15 kW | 42–38 CFM |
| OF-P-M-30 | 12 kg/cm² | 30 / 22 kW | 58–52 CFM |
* Perfect for clean-room and hygiene-critical industrial operations with oil-free air certification.
Share your HP, pressure or application and get the right machine, price and delivery for your plant.
